RJ2 Series 650℃ Pit-type Tempering Furnace

The RJ2 series 650℃ pit tempering furnace is suitable for tempering heat treatment of metal parts and light alloy parts. Its rated temperature is 650℃, and the maximum temperature can reach 650℃. It is widely used in annealing, tempering and solution treatment of steel parts, light alloy parts, etc., and is particularly suitable for heat treatment of long rod-shaped, shaft-type parts and light alloy parts.
The equipment adopts a cylindrical furnace shell welded from high-quality steel plates and steel sections, lined with lightweight energy-saving refractory bricks, and supplemented with aluminum silicate fiber wool and thermal insulation silica bricks as insulation materials to ensure that the furnace structure is sturdy and durable and has excellent thermal insulation effect. The heating element uses high-resistance alloy wire (such as 0Cr25Al5), which is wound into a spiral shape and installed on the inner wall of the furnace. With the advanced hot air circulation system, the temperature uniformity in the furnace is controlled within ±5℃.
The RJ2 series pit tempering furnace is equipped with an advanced temperature control system, which has the characteristics of high-precision temperature control and strong stability. The equipment is also equipped with a ventilator and an air guide device to stir the air in the furnace to further improve the temperature uniformity. In terms of safety design, the equipment is equipped with interlocking devices and over-temperature protection functions to ensure safe operation.
The RJ2 series pit tempering furnace provides a variety of models to meet the needs of different workpiece sizes and quantities. It has a beautiful appearance and convenient operation, and is suitable for scenes with high requirements for temperature uniformity and heat treatment quality in industrial production.
